Hand push floor scrubber - ERIClean E531BD
E531BDHand Pushed Floor Scrubber
Balanced ability, high cost-effectiveness
Advantages
Largeopeningrecovery tank,reversible and tool - freedisassembly design for recovery tank cover,easy to clean andmaintain;
Touch switch operation panel,simple and reliable operation, lowmaintenance cost;
Large water inlet in front of solution tank, easy and quick to addwater;
Aluminum die-casting brush deck and squeegee frame withsurface coating, which is durable and antirust;
The patented brush system is designed for brush pressureadjustment,and it”s easily cope with different floor cleaningrequirements, efficient and reliable;
Efficient noise reduction system,which can effectively reducethe machine sound level during work;
Efficient and reliable mechanical defoaming system and water-full alarm of recovery tank, greatly improving the lifetime of vacuummotor;
Soft start design for both brushless brush motor and brushlessvacuum motor,the controller has digital overcurrent andundervoltage protection functions;
High efficiency brushless motor customized model with longerlifetime, more reliable quality, and one full battery charge can keepmachine working 4-6 hours;
Patented design for brush adapter, which can realize automaticloading and unloading of brush plates, longer lifetime.
Technical Spec | Unit | E531BD |
Clean productivity theoretical/Actual | ㎡/h | 2650/2100 |
Scrubbing width | mm | 760 |
Washing width | mm | 530 |
Max. speed | Km/h | 5 |
Solution tank capacity | L | 50 |
Recovery tank capacity | L | 45 |
Voltage | V | 24 |
Brush motor rated power | W | 480 |
Vacuum motor rated power(Eco/Strong) | W | 400 |
Drive motor rated power | W | 150 |
Brush/Pad diameter | mm | 510/510 |
Brush speed | Rpm | 153 |
Brush pressure | Kg | 21/28 |
Vacuum power(Eco/Strong) | Kpa | 12.5 |
Sound level at 1.5m | dB(A) | <68 |
Battery compartment size(LxWxH) | mm | 340*340*230 |
Recommend battery capacity | V/Ah | 2 * 12V100Ah |
Working hours | Hour | 3-4 |
Gross weight(Include battery) | Kg | 189 |
Machine size(LxWxH) | mm | 1220 x540x1058 |
