Ride-on Scrubber - ERIClean E810R
E810R Ride-on Scrubber
Balanced ability, high cost-effectiveness
Application places:
Hotel, supermarket,hospital,office,station,airport,large parking lot,factory,port and the like.
E810R Product Highlights
E810R is a new designed medium size ride on floor washingmachine with 2*15 inch brushes.Patented central tunnel designchassis design with front drive wheel.Underslung design, smallturning radius and flexible operation, it is very suitable
operation.
120L large capacity solution tank and recovery tank is divided bylow battery compartment and low recovery tank center of gravitydivision design, safe and fast operation both for battery installationand machine maintenance.
The whole machine integrated waterproof touch panel design,easy to operate;
LCD display, visual equipment parameters, easy to read and fastmaintenance;
There are 3 adjustable grades design for clean water volume anddrive speed;
Double electric push rod design for brush and squeegee system,one-key automatic lifting of brush and squeegee system
automatic lifting when machine back off, safe and efficient;
Magnetic type brush /pad connection mode, easy and conve-nient for brush/pad installation and uninstallation;
Large opening of recovery tank, reversible and tool -freedisassembly design for recovery tank cover, easy to clean andmaintain;
Seat safety switch equip on the machine, when driver leave
machine will automatically stop, more safe and reliable operation.
| Technical Spec | Unit | E810R |
| Clean productivity theoretical/Actual | ㎡/h | 5200/4200 |
| Scrubbing width | mm | 1060 |
| Washing width | mm | 810 |
| Max. speed | Km/h | 6.5 |
| Solution tank capacity | L | 120 |
| Recovery tank capacity | L | 120 |
| Voltage | V | 24 |
| Brush motor rated power | W | 380*2 |
| Vacuum motor rated power(Eco/Strong) | W | 500 |
| Drive motor rated power | W | 650 |
| Brush/Pad diameter | mm | 410/410 |
| Brush speed | Rpm | 180~200 |
| Brush pressure | Kg | 45 |
| Vacuum power(Eco/Strong) | Kpa | 15 |
| Sound level at 1.5m | dB(A) | <70 |
| Battery compartment size(LxWxH) | mm | 450*450*298 |
| Recommend battery capacity | V/Ah | 4 * 6V200Ah |
| Working hours | Hour | 4-5 |
| Gross weight(Include battery) | Kg | 320 |
| Machine size(LxWxH) | mm | 1415*865*1120 |
| Accessories:Pad driver*1,brush*1 | ||
Detail display
